#5 Cadillac Eldorado 1968-78 425, 472, 500cid V8 1.4KW + 2KW High Torque Starter Motor TS-1204
Price range: $459.00 through $499.00
- A Durable Ultra-High Torque Starter Motor in a Compact Lightweight design
- 4.4:1 Gear-Reduction design, Internal solenoid solves ‘heat-soak / hot-start problems
- Robust construction using all steel-gears , Increased reliability due to use of all-new modern materials and components.
- Provides more cranking power, draws less current from the battery and weighs a lot less than the original OEM Starter Motor
- High-Torque ideal for High Compression Engines up to 14:1 Compression
- Adjustable Aluminum front housing for increased clearances around exhaust, steering and suspension.
- Will bolt directly to engine with NO modifications
- Water and Corrosion Resistant
- Mounting hardware and terminal fitting kit supplied when applicable.
- OE Reference Part Numbers Delco 1107354,10496868, 1108352, 1108473, 1108518, 1108522, 1108761, 1108767, 1108795, 1109023, 1109027, 1109039, 1109042, 1109069, 1109070, 13006565-101, 19136154, 1988605, 88863067
- Available in 1.4kw ‘Quick-Start’ up to 14:1 Compression and 2kw ‘Ultra-Start’ up to 18:1 Compression Versions
Start strong with Titan Performance Products.
Assembled in New Zealand / Postage 2-5 days / 18 month warranty
Specifications
| Power/Torque | 1.4kw 245nm + 2kw 270nm |
| Pinion/Rotation | 9 Tooth 25mm Diameter / Clockwise |
| Mounting Dimensions | |
| Dimensions/Weight | 160 x 140 x 100 / 3.7kg +4.9kg |
Vehicle Make and Model Compatibility
| Make | Model | Engine Size | Year |
| Cadillac | Eldorado V8 | 7.0L 425cid | 1977-1978 |
| Cadillac | Eldorado V8 | 7.7L 472cid | 1968-1969 |
| Cadillac | Eldorado V8 | 8.2L 500cid | 1970-1976 |
Additional information
| Power Output | TS-1204 'Quick-Start' 1.4kw 245nm, TS-1204-2 'Ultra-Start' 2kw 270nm |
|---|
